Design & Build Custom Workholding
Advanced Design & Build Custom Workholding Fixtures
Toner Machining Technologies provides comprehensive contract engineering and precision manufacturing for high-performance workholding fixtures, custom machinery, gages, and specialized production tooling.
Our degreed mechanical engineers utilize advanced SolidWorks® 3D CAD/CAM software in conjunction with Cosmos Finite Element Analysis (FEA) software to simulate stress, deformation, and clamping forces before manufacturing begins. This ensures maximum rigidity, eliminates part deflection, and optimizes tool clearance for high-velocity machining operations.
Production-Grade Fixturing Capabilities
- Multi-Axis Systems: Custom workholding configurations engineered specifically for Horizontal Machining Centers (HMCs), Vertical Machining Centers (VMCs), and multi-axis CNC production environments.
- Actuation Frameworks: High-reliability design and integration of automated hydraulic, pneumatic, and manual clamping mechanisms tailored for high-volume automotive, heavy truck, defense, and aerospace production runs.
- Enterprise Traceability: Every project is manufactured entirely in-house by expert machinists and assembly technicians, with real-time tracking across our facility using the Global Shop Solutions ERP system to ensure strict adherence to project timelines and critical quality tolerances.
Comprehensive Project Handover & Documentation
Upon project completion, we provide your engineering team with a complete digital project notebook and data package via secure file transfer or encrypted physical media. This comprehensive turnover package includes:
- Quality Assurance Reports: Finalized inspection data and CMM dimensional validation reports.
- Engineering Prints: Detailed, finalized 2D/3D manufacturing drawings and digital CAD files.
- Operational Manuals: Comprehensive operations, maintenance, and preventive care manuals.
- System Schematics: Complete hydraulic, pneumatic, and electrical schematics.
- Lifecycle Support: Full spare parts listings, structural bills of materials (BOMs), and high-resolution digital production photographs for seamless shop-floor integration.
Examples
Ready to find out more?
Contact us for more information on our custom workholding design and build services.
